Ws Type Universal Joints Coupling with High Precision

Overview

Basic Info.

Model NO.	WS
Material	35CrMo
Type	Elastic Coupling
Terms of Shipment	by Sea
Delivery Time	Depend on Your Quantity
Transport Package	Wooden Box
Specification	as your requirement
Trademark	Huading
Origin	China
HS Code	8483600090
Production Capacity	10000pieces/Year

Product Description

WS Type Universal Joint ShaftFeatures:1. It is suitable for transmission coupling space on the same plane of two axis angle beta β≤45°, the nominal torque transmission 11.2-1120N. 2.The WSD type is a single cross universal coupling, and the WS type is a double cross universal coupling.3.Each section between the largest axis angle 45º.4.The finished hole H7, according to the requirements of keyseating, six square hole and square hole.5.The angle between the two axes is allowed in a limited range as the work requirements change.

NO	Tn/N·m	d(H7)	D	L0				L		L1	m/kg				I/kg·m2
				WSD		WS					WSD		WS		WSD		WS
				Y	J1	Y	J1	Y	J1		Y	J1	Y	J1	Y	J1	Y	J1
WS1WSD1	11.2	8	16	60	-	80	-	20	-	20	0.23	-	0.32	-	0.06	-	0.08	-
		9
		10		66	60	86	80	25	22			0.2		0.29		0.05		0.07
WS2WSD2	22.4	10	20	70	64	96	90			26	0.64	0.57	0.93	0.88	0.1	0.09	0.15	0.15
		11
		12		84	74	110	100	32	27
WS3WSD3	45	12	25	90	80	122	112			32	1.45	1.3	2.1	1.95	0.17	0.15	0.24	0.22
		14
WS4WSD4	71	16	32	116	82	154	130	42	30	38	5.92	4.86	8.56	0.48	0.39	0.32	0.56	0.49
		18
WS5WSD5	140	19	40	144	116	192	164			48	16.3	12.9	24	20.6	0.72	0.59	1.04	0.91
		20						52	38
		22
WS6WSD6	280	24	50	152	124	210	182	52	38	58	45.7	36.7	68.9	59.7	1.28	1.03	1.89	1.64
		25		172	136	330	194	62	44
		28
WS7WSD7	560	30	60	226	182	296	252	82	60	70	148	117	207	177	2.82	2.31	3.9	3.38
		32
		35
WS8WSD8	1120	38	75	240	196	332	288			92	396	338	585	525	5.03	4.41	7.25	6.63
		40		300	244	392	336	112	84
		42
